Gotham Audio's 14008, 8 Channel Snake, SOLD PER FOOT, NOT TERMINATED

(No reviews yet) Write a Review
Adding to cart… The item has been added

Double shielded Multipair cable analog Snake 8pair

Each pair of conductors is protected by our exclusive "double Reussen shield". Two layers of copper wires with each 100% coverage secure minimal crosstalkmaximal RF-rejection and excellent flexibility of the whole construction. With this concept of shielding and protection, the cable is the best possible consens of reliability, flexibility and signal protection. All multipair cables are numbered each meter for easy length termination.

Shown 14024 (24pair)

Inner construction each pair similar to 10301 single pair



Construction of Multipair:

1 = Outer Jacket:  PVC, grey (dark)
2 = Viscose fiber coat: Counter wrapped
3 = inner jacket: (Ø 3.3mm)
4 = Shield No. 1: Bare copper wires (0.10 mm) 100% coverage
Shield No. 2: Bare copper wires (0.10 mm) 100% coverage
Insulation (cond): PVC, Ø 1.15 mm, conductors red and white wrapped
Conductor: Stranded bare copper wires 25 x 0.10 mm (0.19mm²) 25x38AWG = 24AWG

Technical Datas:

Conductor resistance:    < 90 ohm/km
Shielding resistance:    < 20 Ohm/km
Capacitance at 800Hz: cond/cond:  < 75 nF/km
  cond/shield:  < 130 nF/km
Temperature range: flexi-installed: -5° to +50° C
  fix-installed: -30° to +70° C

Construction of Multipair: 14008  (8 Pair)

Jacket: PVC, max Ø 14.0 mm dark gray
Spool size: 200m
Weight/m: 0.26 kg
Weight/spool: 52.00 kg
Order No.: 14008
